Bundle Package: PowerTIG 210EXT + PowerPlasma 52i

$3,300.00

  • New Bezel and stackable feature!
  • HV/HF arc starting: No Points to adjust.
  • Fan on Demand upon arc start (**Water Cooler will still run continously**)
  • 120/240V IGBT Module inverter design
  • Digital Microprocessor Control
  • Commercial 60% Duty Cycle at 210 Amps
  • 240V Outlet in rear for optional WC375 water cooler
  • AC/DC TIG/DC Stick functions
  • Improved HF Start
  • AC Frequency/Balance control
  • 3 wave AC Wave forms, Advanced Square, Soft Square, and Triangular
  • Standard and Advanced AC pulse
  • Adjustable Stick Hot Start/Arc Force
  • 9 Channel Programmable Memory
  • Unit Dimensions: 25" x 10" x 18"

In stock

Bundle Package: PowerTIG 210EXT + PowerPlasma 52i $3,300.00

The benefits of the PowerTIG 210EXT digital microprocessor are numerous, it helps increase productivity and and weld quality. The Everlast PowerTIG 210EXT allows you to make precise settings and fine tune them to the exact standards required.  This TIG/Stick welder from Everlast also features IGBT inverter technology which offers the best in arc stablity and performance while reducing size and weight.  The unit features wave form control with three distinct wave forms: Advanced Square wave, Soft Square wave and Triangular  that offer flexibility while welding aluminum. The Everlast PowerTIG 210EXT features programmable memory, adjustable AC Frequency, and adjustable AC balance control.  The stick welder function features adjustable hot start and arc force control for maximum welding flexibility.  The PowerTIG 210EXT features two pulse modes, standard and advanced pulse.  In the advanced pulse mode the welder oscillates between AC and DC polarity allowing fine fast freeze control on thin gauge aluminum, and greater penetration on thick plate aluminum.   The Everlast PowerTIG 210EXT may seem quite complex with its list of features, but it is really quite simple because of the intuitive design which leads to quick and easy setup whether you are a welding professional or just an enthusiast.

The PowerPlasma 52i is an IGBT plasma cutter that is capable of cutting 1/2″ and can sever up to 3/4″ thick steel.  The PowerPlasma 52i offers plenty of capability for the average small fab shop or hobbyist.  The latest generation Everlast PowerPlasma 52i is fully digital and features the Italian designed iPT 60i torch. CNC port is also standard on this unit for cuts up to 1/4″.

For more information on the PowerPlasma 52i:  https://everlastwelders.ca/product/powerplasma-52i/

Features & Benefits
  • New Bezel and stackable feature!
  • Microprocessor control offers precise management of welding parameters and functions
  • Offers standard type pulse feature for AC and DC, and a special Advanced Pulse for AC for welding thin material
  • Wave form control offers 3 types of wave form for AC welding: Triangular Wave, Advanced Square Wave, and Soft Square Wave
  • Programmable Memory allows user to save parameters for up to 9 different programs
  • HF or Lift Arc capability in AC or DC modes
  • Offers programmable Stick functions which include hot start time, hot start intensity and arc force control.
  • NOVA Foot pedal
NOTE: When used with a generator, the generator must be certified by its manufacturer to produce "clean" power. 5% or less Total Harmonic Distortion (THD)
What's Included
  • 7.5m Everlast #26 series (air cooled) TIG torch with 35 series DINSE style connectors and torch switch for 2T/4T operation
  • 7.5m Everlast #9 series (air cooled) TIG  torch with 35 series DINSE style connectors and torch switch for 2T/4T operation
  • Heavy Duty Stick electrode holder with 3m cable and 35 series DINSE connector
  • Heavy Duty Work clamp with 3.5m cable and 35 series DINSE style connectors
  • NOVA Foot pedal
  • Everlast Argon regulator
  • 240/120V Pigtail Adapter
  • Basic consumable starter kit (Tungsten not included)
  • 1.8m Power input cable with NEMA 6-50 Plug
Tech Specs
IGBT Type:
Module IGBT
Inverter Type:
Digital/Micro-controlled
Output Type:
AC/DC TIG, DC Stick
Voltage/phase:
DUAL VOLTAGE 120/240 1 PHASE
Max Rated TIG Amps:
210 A
Max Rated Stick Amps:
160A
TIG Amps @ Rated Duty Cycle:
  • @120V:  125A/15V @ 60% Duty Cycle/ 40° C
  • @240V: 210A/18.4V @ 60% Duty Cycle/ 40° C
Stick Amps @ Rated Duty Cycle:
@120V:
  • 100A/24V @ 60% Duty Cycle/ 40° C
  • 80A/23.2V @ 100% Duty Cycle/40° C
@ 240V:
  • 160A/26.4V @ 60% Duty Cycle/ 40º C
  • 130A/25.2V @100% Duty Cycle/40°
Max Inrush ( I1MAX ) Amps:
  • @120V:  27A
  • @240V: 31A
Maximum Rated (I1EFF ) Input Amps:
  • @120V: 22A
  • @240V:25A
OCV:
  • 70V/24V with VRD
TIG Output Range DC:
  • 120V: 3A-120A/10.1V-15V
  • 240V: 3A-210A/ 10.1V-18.4V
TIG Output Range AC:
  • 120V: 5A-120A/10.2V-15V
  • 240V:  5A-210A/10.2V-18.4V
Stick Output Range DC:
  • 120V: 20A-100A/20.8V-24V
  • 240V:  20A-160A/20.8V-26.4V
Stick Hot Start Amps:
0-100%
Stick Function:
Adjustable Arc Force Control
Stick Hot Start Type:
Adjustable Hot Start
Stick Hot Start Time:
0-2 Seconds
6010/Cellulose Capable:
Yes (Short Arc) Limited to 6011
Minimum Amp DC TIG Start:
5A
Minimum Amp AC TIG Start:
5A
TIG Start Type:
HF and Lift Start
Memory:
Yes
Start Amp Range:
120V:
  • DC: 5-120A
  • AC: 5-120A
240V:
  • DC: 5-210A
  • AC: 5-210A
End Amp Range:
120V:
  • DC: 3-120A
  • AC: 5-120A
240V:
  • DC: 3-210A
  • AC: 5-210A
Upslope Time:
0-25 Seconds
Down Slope Time:
0-25 Seconds
Preflow time:
0-25 Seconds
Post Flow Time:
0-50 Seconds
TIG Pulse:
Yes
Standard DC Pulse Frequency:
.1-500 Hz
Standard AC Pulse Frequency:
.1-250 Hz Advanced Square Wave .1-10 Hz Soft Square, Triangular
AC Advanced Pulse Frequency:
.1-10 Hz
Pulse Time On (Duty Cycle):
5-100%
Pulse Amp Range:
5-99% of Welding Amps
AC Frequency (Hz):
20-250 Hz
AC Balance Range:
5-90% of EP (+)
AC Wave Forms:
  • Advanced Square Wave
  • Soft Square Wave
  • Triangular
Remote Control:
2T/4T with Torch Amptrol settings
Foot Pedal:
NOVA
Minimum Maximum
  • Weld steel to a maximum of 5/16" single pass
  • Weld Steel to a maximum of 3/4" multi-pass
  • Weld Aluminum to a maximum of 1/4" single pass
  • Weld aluminum to a maximum of 5/8" multi-pass
  • Weld to a minimum of .007" Steel
  • Weld to a minimum of .008" Aluminum
  • Weld with a minimum of 1/16" diameter electrode
  • Weld with a maximum of 1/8" diameter electrode
Optional Equipment
  • Everlast Series Rotating Head TIG Torches
  • Everlast Series Slim Line Flex Neck Series
  • Everlast Series ProFlex Series
  • Amperage Slide Control
  • WC375 Water  Cooler
  • ProCart
  • Welder Cover
Notes For generator use:  Use only generators that are certified as "clean power" by the manufacturer.  This means that the unit has less than 5% THD (total harmonic distortion)
